Assist (VLM)

Assist… asks the VLM about a part of your data and shows you what it suggests. It is on a cluster page (the whole cluster or the open sub-cluster, or the crops you selected), on one crop's details panel, on one box in Review, and on Matching items (everything a filter matches). The concept, the sample sizes and the API are in Selective VLM and segmenter assist.

The VLM only suggests. A label a human or an import set, a validated label and a test-holdout item are never overwritten; what the VLM said about them is shown next to the label as "VLM said". Everything on the page, the counts and the refusals included, is what the backend answered.

The dialog​

The Assist dialog: nothing is written until you press Start run
  1. What the VLM sees.
    • Selected: the crops (or boxes) you picked. Shown only when you selected some.
    • All members: every member of the cluster, sub-cluster or filter the VLM may see.
    • Random representative sample: a seeded sample that grows with the size of the scope and is spread over the sub-clusters. Leave the size empty for the server's default, or type one; the seed makes it repeatable.
  2. What to do. Classify, Attributes, Verify boxes and Segment; only the actions that fit the target are offered (a box is not classified, a cluster is not verified). With Segment, choose how the segmenter's new boxes are verified: by the project's active VLM, or accepted without one. Ticking Verify boxes together with Segment judges the new boxes with the endpoint you chose for this run.
  3. Which VLM. The project's active endpoint, or any registered endpoint for this run only, and a prompt pack. An endpoint that sends crops outside the deployment shows its warning and needs your acknowledgement. See VLM models.

Every change asks the server for a dry run, shown at the bottom: how many of the scope's members go to the VLM, the estimated number of VLM calls, the sub-cluster spread, what is left out (holdout, ignored, locked) and the endpoint and pack the run will pin. If the server refuses (no VLM is configured, another run is live, the scope is too large, the pack declares no attributes), its reason replaces the figures and Start run stays disabled.

Start run posts the same request for real. The dialog follows the run: Queued, Running with progress, and for a Segment run Waiting for the region worker until the worker has written the boxes. When it ends, the served counts are listed (answered, written, kept as suggestions on locked items, failed; boxes judged; segmenter items done and pending). You can close the dialog while it runs; Cancel run stops it after the current chunk and what it wrote stays. Only one run is live per project.

The proposal for a cluster or sub-cluster​

A Classify run over a cluster or sub-cluster reads the sampled answers as a label. On the cluster page a folded line, "VLM proposal for cluster #…: class, 83% of 41 answers", opens the proposal card:

  • the proposed class and the agreement: how many sampled answers named it, and the gate it had to pass. If no class reached the gate the card says so and shows only the votes; Use on a row picks a class from them.
  • the votes per class, and the new class names the VLM proposed that the registry lacks (with Add class… to create one).
  • the attribute suggestions, labelled "suggestions, not labels".
  • Apply {class} to {N} members: the explicit button. N is the server's dry-run count of members it would label; the members it leaves alone (locked, validated, held-out) are counted next to it. Applying labels them as you would by hand (validated, trainable).

The card marks a proposal stale when the scope has changed since the run, for example after Refine (AHC) (it shows how many of the members now were in the run). Apply then refuses with the backend's scope_changed message; run again on the current members. Count the current members anyway is offered only after that refusal, and still counts first.

Attribute suggestions​

Attributes a prompt pack declares appear as dashed VLM suggests chips with the VLM's confidence, on the crop card, in the crop details panel and in Review, and per box on the Review box row. They are never labels and never change the class or the boxes. When the VLM's class answer differs from a locked label, the card shows VLM said: {class} beside it.

Region verification on the VLM scope panel​

On Settings, the VLM scope panel has a Region verification choice: Verify with the VLM (the region worker asks the project's VLM about each box the segmenter proposes) or Accept without a VLM (boxes are accepted as they are, even with a VLM active). It is saved with the scope and applies to the whole project; a Segment run can choose otherwise for its own items.

Sub-cluster tabs​

After Refine (AHC) the cluster page lists the sub-clusters as tabs. A tab asks the server for that sub-cluster's members (cluster_subid), so a sub-cluster larger than a page is listed whole and Assist… on it targets exactly it. The tab list is built from the sub-clusters seen while the whole cluster is shown; scroll the all view to load the rest.
